Factory Price! Vacuum Silicone Membrane Press / Corian Forming Machine
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Type: | Factory Price! Vacuum Silicone Membrane Press / Corian Forming Machine | Working Speed: | 2-3 Min/1 Door |
|---|---|---|---|
| Maximum Press Hight: | 80mm | Vacuum Pump: | Germany Becker 70 |
| Negative Pressure: | 0-0.095 Mpa | Working Voltage: | 380 V/50 HZ Or Customized As Your Request |
| Vacuum Membrane Press Table Size: | 2550*1150(1300)*50mm | After-sales Service Provided: | Engineers Available To Your Factory |
Factory Price! Vacuum Silicone Membrane Press / Corian Forming Machine
Introduction
Economic Model Double Worktables Manual PVC Vacuum Membrane Press Machine ( TM2480C2) is suitable for a variety of surfaces furniture,wardrobe cabinets,Dingguxian,sliding doors and other stickers cover(can stick coated with PVC film and the transfer materials ,silica gel plate after installation can be pasted on one side of the core board or veneer leather).
TM2480 automatic vacuum laminating machine is mainly appliedto manufacturing and decoration and furniture industry, can be agents of traditional paint process, a variety of decorative panels, furniture and
other decorative surface, suitable for surface mount MDF coating PVC, veneer , ABS plastic and other plastic materials, equipment is simple
Specifications
Model: TM2480
Total power: 38KW
Working area size : 2550*1250*60mm
Machine overall size: 9200*2200*1750mm
Vacuum pump model: XD-063A
Vacuum pump type: Luozi pump
Heating method :Alumium panel radiating
Heating type:Resistance wire heating
Max processing length :2440mm
Max processing width:1220mm
Max processing thickness:60mm
Working table move speed :10m/min
Max vacuum: -0.1Mpa
Max temperature: 320 degree
Vacuum tank volume: 0.462M2(square meter)
This model used to cover PVC on the surface of all kind of doors and furniture.
Double working tables
Main Features
1. Manual Curved Surface PVC Vacuum Membrane Press Machine ( TM2480C2) model operation is subject to light instruction, every step is finished by manual operation, economical and practical.
2. Heat with electric aluminum plate, PVC surface heating temperature is very uniform and not easy to change color.
3. Adopts top vacuum pump, fast pumping speed, big power, rated pumping speed is 40m3/ h ( optional)
4. Control electrical appliance uses well-known brands, not easy to be damaged and convenient for maintenance.
5. Use high quality heat preservation material, good heat insulation effect and energy saving.
6. All ready-to-ship machines inspected by overseas dept. staff independently with detail photo and video to customers. We are trying all the best to insure your worry-free on both purchasing and running of all our machines.
|
Overall Dimension |
6800×1700×1400mm |
|
Platen Size |
2500×1300(1100)×60mm |
|
Rated working pressure |
Negative pressure ≥-0.095Mpa |
|
Power |
20kw |
|
Heating |
new materials aluminum wire(heating is even) |
|
Actual Power Consumable |
5kw |
|
Weight |
1.5T. |
|
Voltage |
380V 50HZ |
|
Packing Size |
3400×1800×1850 |
|
Delivery time |
15 days after receiving advanced payment |
Please kindly check Youtube link of our machines if you're interested.
We do supply a whole life after service maintenance and tech support .you can call us any time .
